The triphenylphosphine–benzotrifuroxan reaction. Part V. Crystal and molecular structure of a ‘blue compound’, 8,8′-bis(triphenylphos-phoranylidene)bi(benzo[1,2-c:4,5-c′]difurazan-4-ylidene)
Journal of the Chemical Society C: Organic Pub Date : , DOI:10.1039/J39690002292
Abstract

The blue crystalline compound isolated from the benzotrifuroxan–triphenylphosphine reaction has been shown to be 8,8′-bis(triphenylphosphoranylidene)bi(benzo[1,2-c:4,5-c′]difurazan-4-ylidene) by three-dimensional X-ray structural analysis. The central heterocyclic system is overcrowded and not planar. Each of the C6 rings is boat-shaped although the individual carbon atoms are trigonal planar. The average value of the carbon–carbon bond length in this system 1.46 Å is significantly longer than in a benzenoid system. Other mean bond lengths are P[double bond, length as m-dash]C 1·74, C[double bond, length as m-dash]N 1·32, and N-O 1·40 Å.
